Advanced PVC Disc Grinder Mill Pulverizer Machine for Scrap Plastic
Processing Crushing Shredding
Short description:
Plastic Pulverizer Machine/PVC Pulverizer Machine/LDPE Pulverizer
Machine is usually used in plastic recycling processing. Before
starting to extrude perfect pipes, the machine line will produce
many waste plastics. The waste plastics, if throw out will be bad
for the environment and increase the cost. The crusher can make the
waste material into flakes. The plastic pulverizer can make the
flakes into powder. And then the powder will be transported for
further processing such as mixing or extrusion.
Application Areas:
PVC Scrap Recycling Pulverizer Mill Machine is designed by our
factory using Germany technology and our own production experience.
PVC pulverizer machine is used to grind waste SPC floor, PVC
ceiling, PVC pipe, PVC profile, PVC marble sheet into a fine
powder. The capacity can be from 100-900kg/h.
Description:
This PVC Plastic pulverizer is chiefly designed to milling PVC. The
pulverizer uses turbo type blade. The static blade and rotary blade
could be adjusted, thus you can get different sizes of PVC powder
with one grinder. High output, low energy consumption, and a long
lifespan attract many customers around the world. It can be used
for PVC plastic from PVC pipe/profile/soft sheet/bottle/card from
low to moderate hardness PVC.
The output of our plastic pulverizer can reach 100-900kg/h
(15-100mesh).
The plastic pulverizer machine is mainly composed of the electric
motor, disc type blade, feeding fan, vibrating sieve, dust removing
system, etc.
According to the customer's needs, you can choose some accessories,
such as a converter, vacuum loader, screw loader, magnetic net,
metal separator, chiller, pulse dust collector, metering and
weighing packaging machine, etc.
Technical Features:
1. THe plastic pulverizer can easy to grind all kinds of Hard &
Soft PVC into powder.
2. The dust collector is added to effectively reduce dust
pollution.
3. The discharging of the main fan reduces the labor intensity of
operating workers.
4. The door cover of the host can be opened for the convenience of
maintenance and replacement of cutters.
5. The mill uses the water and wind double cooling system, Prevent
bearing, and other parts from overheating.
6. The powder mesh is adjustable(15-100mesh).
7. Easy installation and maintenance, just open the door to clean
up.
8. Using Well-known brand accessories, such as motors, can work for
a long time, saving the trouble of changing accessories frequently.
9. With a wide range of optional accessories, professional
solutions can be developed based on the customer's budget and
processing requirements.
Delivery information:
1. Delivery: 30 days after ur order
2. Warrenty: 12 months
3. Payment: T/T 30% in advance, T/T 70% before delivery.
4. Packing: Standard export wooden case
Technical Parameters:
| Model | P500 | P600 | P800 | P1000 |
| Capacity | 100-300 | 200-500 | 300-800 | 400-900 |
| Motor power(kW) | 37-45 | 45-55 | 75-90 | 90-110 |
| Diameter of miller (mm) | 500 | 600 | 800 | 1000 |
| Diameter of vibration sieve (mm) | 800 | 1000 | 1200 | 1500 |
| Power of vibration sieve (kW) | 0.75 | 0.75 | 0.75 | 1.1 |
| Rotor milling knife (pcs) | 22 | 26 | 28-32 | 36-40 |
| Stator milling knife (pcs) | 12 | 15 | 20 | 26 |
| Size of input particle (mm) | 6-8 |
| size of finished powder (um) | 300-1000 |
| Dimension | 3500*1300*3700 | 3700*1450*3700 | 4300*1700*4000 | 5000*2000*4300 |
Our Service:
1. One year guarantee for whole machine.
2. 24 hours technical support.
3. Our engineers can provide installation & commission service
overseas.
4. After a year, we can instruct you how to maintain the machine,
and spare parts are provided with the best price.
5. We also can provide training service which help operators handle
the machine well.
Product details:
Company profile
Service and support
Our factory
Certificate
F & Q:
Are you a trading company or factory? Can I have a factory
visiting?
We are a factory that produces machines for customers directly.
Yes, our production plant can be visited at any time. We are in
Zhangjiagang, Jiangsu Province close to Shanghai and Wuxi. If you
are near to us, the pick-up service is available.
How to build trust with Langbo
We can send working videos showing the machine running perfectly in
several countries for online communication. We will provide
customer-focused and tailored technical suggestions.
For offline contact, you can visit our factory and talk about the
machine face to face, you can find our competence in the field of
plastic extrusion and tell our ability in machine building.
Is the shipping cost included in the quotation?
Usually, our quotation contains FOB Shanghai as a shipment
condition. This means the shipping cost between the delivery and
destination ports will not be included in the quotation. The
shipping cost fluctuates according to the delivery company and
shipping date. Langbo can help customers to get the latest shipping
price. Customers decide if we add the shipping cost to the
quotation or choose a shipping agent by themselves.
What will happen after order confirmation
confirmation of Configuration
Sign of Proforma invoice
30% of total price pre-payment for production starting
Test running in the house, customers on-site or video connecting
Confirmation of machine condition
70% of the total price for delivery preparation
Confirmation of Delivery date
Shipping to customer
On-site commissioning
Training in machine operation and maintenance
Confirmation of handover
One year guarantee
Whole lifecycle service and technical support
What is the Payment Method?
T/T, D/P, Letter of credit, Cash transaction
How to guarantee the machine quality made by Langbo
We provide one year guarantee and whole-lifecycle technical support
for our product. During in-house test running, customers can check
the machine on-site. Any point for optimization will be done
immediately.
How can customers get the exact machine as they wish?
Factory visiting before order
Product sample posting to Langbo for a better understanding of
customer’s expectations and configuration communication
On-site checking during test running
Do you have CE Certification?
Yes. Both our extrusion machine and plastic recycling machine have
CE Certification.
What is the delivery time between order confirmation and delivery?
Usually 45 days. Depended on the certain project, the exact
delivery time will be wrote on contract.
What are services for after-sale
One-year quality guarantee.
Quick response for technical support
Problem analysis for production problems
What means one-year quality guarantee
After the handover of the machine, Langbo provides free new parts
for every non-man-made damage.
How to get the required area of the machine?
For a new plant, you can contact me. (sales@langbochina.com/ whatsapp:8615962377824) After knowing your demand, I can make the
detailed solution and layout of the machine line. Meanwhile, I will
provide technical guidance of your installation and specification.
